For any unwanted hairs on areas of face, arms, armpits, chest, back, bikini, legs and etc.

(including light, blond and thin hairs)
Working Principle
Diode laser hair removal technology is based on the selective dynamics of light and heat. The laser goes through the skin surface to reach the root of hair follicles; light can be absorbed and converted into heat damaged hair follicle tissue, so that hair loss regeneration without injury surrounding tissue. Slight pain, easy operation, the most safe, technology for permanent hair removal now. It is performed using gold standard 755nm+808nm+1064nm diode laser technology, with energy penetrates deep into the dermis with high average power and a rapid 10 pulse-per-second repetition rate to heat the hair shaft and hair follicle, rather than destroy the oxygen organization around hair follicle. Meanwhile, contacting surface cooling technology applied on the Sapphire Dual-Chill Tip can eliminate the heat effect attributed to optical energy, greatly improving both the treatment performance and safety.
Top level Innovative, humanized
and ELEGANT Design!



Technical Specifications
Laser Type Diode Laser
Laser Stacks Power600W
Wavelength (Spectrum)755nm+808nm+1064nm
Energy Density (Fluence)166J/cm2 (Continuously adjustable)
Spot Size15x15mm2
Dual chiller25*25mm
Pulse Repetition Rate1-10Hz
Pulse Duration10-400ms
PulsesSingle

Cooling
• Continuous Sapphire contact cooling(-5℃~1℃)
• Air cooling
• Closed water circulation cooling
Stand-by WorkingContinuously for 20 hours
Display10" True Color LCD Touch Screen
Electrical Requirements110/230VAC, 15/20A max., 50/60Hz
Net Weight
55kgs
Dimensions (WxDxH)
450*550*1000 mm
Before & After
Hair Removal System
QM-808-5
